2021 Harley-Davidson Cruiser Fat Boy 114
2021 Harley-Davidson FLFBS Fat Boy 114
The original fat custom icon, now with bright chrome finishes
- Hot rod riders who like satin chrome and a steamroller stance
- Commanding the road with fat tires and a squared-up headlamp
- Milwaukee-Eight® 114 V-Twin engine and Lakester disc wheels
Engine
- Displacement:114 cu in (1,868 cc)
- Compression Ratio:10.5:1
- Engine:Milwaukee-Eight® 114
- Bore:4.016 in.
- Stroke:4.5 in.
- Fuel system:Electronic Sequential Port Fuel Injection (ESPFI)
- Exhaust:2-into-2 staggered; catalyst in muffler
Dimensions
- Fuel Capacity:5 gal.
- Length:93.3 in.
- Wheelbase:65.6 in.
- Ground Clearance:4.5 in.
- Tires, Front Model:160/60R18,70V,BW
- Tires, Rear Model:240/40R18,79V,BW
- Rake:30
- Seat Height, Laden:25.9 in.
- Trail:4.1 in.
- Oil Capacity (w/ Filter):5 qt.
- Weight, as shipped:671 lb.
- Weight, in running order:699 lb.
Other
- MfrModelID:FLFBS
- Family Name:Cruiser
- Manufacturer Type:Cruiser
- :Optional
- Primary Color:BlackJackMetalic
- Engine Torque Testing Method:J1349
- Engine Torque:119 ft-lb
- Engine Torque (RPM):3000
- Lean Angle, Right (Deg.):25.6
- Lean Angle, Left (Deg.):25.6
- Fuel Economy Testing Method:Estimated City/Hwy
- Fuel Economy:47 mpg
- Wheels, Front Type:Machined, Lakester cast aluminum
- Wheels, Rear Type:Machined, Lakester cast aluminum
- Brakes, Caliper Type:4-piston fixed front and 2-piston floating rear
- Lights (as per country regulation), indicator lamps:High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS, security, low battery voltage, low fuel
- Gauges:5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication
- Gear Ratios (Overall) 1st:9.311
- Gear Ratios (Overall) 2nd:6.454
- Gear Ratios (Overall) 3rd:4.793
- Gear Ratios (Overall) 5th:3.882
- Gear Ratios (Overall) 6th:3.307
- Gear Ratios (overall) 4th:2.79
- Primary Drive:Chain, 34/46 ratio
